Stuermer Aircraft AIRBOY SILENCE 221 OF E Piston compressor 230V

TECHNICAL DATA Stuermer Aircraft AIRBOY SILENCE 221 OF E Piston compressor 230VGeneral FeaturesAir outlet – ¼“Mobile / Stationary – MobilDimensions and weightsLength (product) approx. 370mmWidth/depth (product) approx. 355mmHeight (product) approx. 330mmNet weight approx. 16.4kgElectrical DataSupply voltage 230VMains frequency 50HzDelivery power 0.9kWAbsorbed power 1.13kWDuty cycle drive motor 70%Noise emissionSound power level Lw78dB(A)Explanation sound power level LwSound power level according to DIN EN ISO 3744 (RL 2000/14/EG)Sound pressure level Lp67dB(A)Explanation sound pressure level LpSound pressure level at 1 m distance according to DIN 45635 T 13CompressorCompressor systemWDSOil-free / oil-lubricatedÖlfreiSuction capacity approx.221l/minFilling capacity approx.120l/minExplanation filling capacityat 6 bar working pressureNumber of cylinders2Number of compressor stages1Compressor speed2800min¯¹Compressed air tankMaximum pressure8barPressure vessel capacity6l
